Control Hire’s 500mm Industrial Axial Fans are designed for the construction market and mounted on wheels and with handles to ensure the ease of moving them around the site. With a powerful motor capable of 11,160m³/hr of airflow and the option of running long ducts for extraction or forced ventilation.
Our range of Industrial Axial fans are manufactured onsite locally in Australia and can extract dust, fumes, and smoke. They are available in a range of varying diameters, motor size, and intrinsically safe options, and are used for dust, smoke or fume extraction.
Key Applications:
Ventilation Solutions for:
Tunnels
Shafts
Basements
Mines
Enclosed Areas
Warehouse
Factory
Construction Site
Underground Works
SPECIFICATIONS
Noise Level: 80dBA @ 1m
Motor: 2.2kW, 12.2A, 2820rpm
Connection 240V, 1 Phase, 15A
Duct Diameter: 500mm
Dimensions 634L x 625W x 881H
Weight: 69kg
Lifting Method: Handles
Temperature: Range: -20°C to +55°C
Thrust: 64N
Fan Performance
Detailed fan performance curves (static pressure vs airflow) are available for all axial fan sizes. Our engineering team can provide Graph 5 — Axial Fan Curves showing performance data for the 500mm, 710mm, 1000mm, and 1250mm models to assist with ventilation design and equipment selection.
Contact our team for site-specific ventilation calculations and fan selection guidance.
