Control Hire’s 619mm Industrial Centrifugal Fans are designed for the construction market, with a powerful motor capable of 19,000m³/hr of airflow and the option of running long ducts for extraction or forced ventilation.
Our range of Industrial Centrifugal Fans are manufactured onsite locally in Australia and can extract dust, fumes, and smoke. They are available in a range of varying diameters, motor size, and intrinsically safe options, and are used for dust, smoke or fume extraction.
Contact us at Control Hire to enquire pricing and stock levels of the ventilation equipment we offer.
Key Applications:
Ventilation Solutions for:
Tunnels
Shafts
Basements
Mines
Enclosed Areas
Warehouse
Factory
Construction Site
Underground Works
SPECIFICATIONS
Noise Level: 84dBA @ 1m
Motor: 5.5kW, 11.0A, 1470rpm
Connection: 415V, 3 Phase,32A, 4 Pin
Duct Diameter: 500mm
Dimensions (mm): 1644L x 982W x 1412H
Weight: 360kg
Lifting Method: Forklift/Lifting Slings
Temperature: -20°C to +55°C*High-Temperature available on request
Options:
Silencers
Zone 1/2/21/22
20 Amp plug
Speed Controller
Constant volume function
Fan Performance
Detailed fan performance curves (static pressure vs airflow) are available for all centrifugal fan sizes. Our engineering team can provide Graph 6 — Centrifugal Fan Curves showing performance data for the 337, H-507, H-510, and 619 models to assist with ventilation design and equipment selection.
Contact our team for site-specific ventilation calculations and fan selection guidance.
