Control Hire’s bespoke solution for serious hazard control. This Air Scrubber can be setup with multiple-stage, HEPA filtration, filtering up to 99.97% of dust captured.
The unit is powered by a powerful 500mm Centrifugal fan the fan will extract dust and fumes through the through the customisable filters. The air being discharged from the fan has been filtered and you can direct this filtered air with ducting up to lengths of 90 metres.
This Air Scrubber is ideal for capturing and removing hazardous dust such as respirable crystalline silica (RCS) and lead, particularly in live environments.
Key Applications:
Filtering dust particles, fumes and mold contaminants resulting from:
Grinding
Cutting
Excavating
Tunnelling
Mining
Sanding
Welding
Metalworking
Painting
Blasting
Manufacturing
Material Processing
specifications
Max Air Flow: 15,000 m³/hr
Motor Power: 5.5 kW / 15 kW
Power Supply: 415V, 32A, 3-Phase
Duct Diameter: 508 mm
Dimensions (L x W x H): 2012 x 1690 x 1700mm
Lifting Method: Forklift and Lifting Points
Filtration: Multi-Stage (F5 Pre-Filter, F9 Secondary Filter, H13 HEPA Filter, Carbon Fume Filter)
Pressure Monitoring: Pressure Gauge, Light and Sound Alarm
Stackable: Yes
Weight: 650 kg (without filters)
Available Filters
| Filter Type | Max Temp (°C) | Airflow (m³/h) | Pressure Drop (Pa) | MERV Rating | AS Performance | Dimensions (mm) |
|---|---|---|---|---|---|---|
| G4 Pad | 80 | 3400 | 90 | MERV 8 | G4 | 12 x 610 x 610 |
| G4 Pad Ring | 80 | 3400 | 90 | MERV 8 | G4 | 5 x 595 x 595 |
| F5 Pleated | 70 | 3400 | 60 | MERV 10 | F5 | 96 x 595 x 595 |
| F5 Bag | 70 | 3400 | 65 | MERV 10 | F5 | 96 x 592 x 592 |
| F9 V-Bank | 70 | 3400 | 125 | MERV 15 | F9 | 292 x 595 x 595 |
| H13 HEPA V-Bank | 70 | 3400 | 250 | MERV 17 | H13 | 292 x 592 x 592 |
| H13 HEPA | 110 | 2700 | 250 | MERV 17 | H13 | 292 x 610 x 610 |
| Activated Carbon V-Bank | 50 | 3400 | 190 | MERV 13 | Carbon | 292 x 595 x 595 |
3-Stage Filtration System
Stage 1: F5 Pleated Pre-Filter
Blocks coarse dust, lint, and pollen. Extends the lifespan of HEPA and carbon filters downstream.
Stage 2: H13 HEPA Filter
Achieves ≥99.95% removal efficiency at 0.3μm. Captures ultrafine particulates including Respirable Crystalline Silica (RCS).
Stage 3: Activated Carbon Filter
Absorbs volatile organic compounds (VOCs), fumes, odours, and chemical vapours.
