Product Details
The Single Arm Welding Fume Filter is built for workshops or construction sites running light to medium-duty welding, where fumes need to be captured close to the arc rather than relying on general room ventilation. An articulating extraction arm positions easily over the work, with a choice of reach options to suit different bench and bay layouts.
At the heart of the unit is a large cassette-style filter with one of the biggest surface areas in its class, paired with a washable metal pre-filter that captures larger particulate and provides spark entrapment. A filter-saturation indicator on the front gradually shifts from white to red as the filter loads, giving a clear visual cue for when maintenance is due: and an optional activated carbon stage helps control odours in enclosed work areas.
A stainless-steel-ready configuration is also available, fitted with a high-efficiency filter cartridge suited to stainless steel welding fume extraction.
As a guide, the standard filter is well suited to annual consumption of up to 750 kg of solid wire, 450–500 kg of flux-cored wire or electrodes, and unlimited TIG use: contact Control Hire for guidance on the right setup for your welding volume.
Control Hire is a construction safety equipment hire business that specialises in products that manage dust, ventilation, noise and fumes on construction sites.
Key Applications:
Fume extraction for:
Arc Welding
MIG, TIG and Stick Welding (Light to Medium Duty)
Stainless Steel Welding (with stainless-ready configuration)
Suited to:
Fabrication Workshops
Maintenance Welding Bays
Multi-Station Work Areas
Source Capture as an Alternative or Complement to General Ventilation
Technical Data
Extraction capacity – Up to 1,250 m³/h at the arm
Filtration – Cassette-type mechanical filter, large surface area (Class M)
Pre-filter – Washable metal pre-filter with spark entrapment
Optional filtration – Activated carbon stage available
Filter monitoring – Visual saturation indicator (white to red)
Air outlet – Vertical discharge
Sound level – Quiet operation, approx. 69 dB(A)
Extraction arm – Multiple reach options available
Power supply – Single-phase or three-phase configurations available
Mobility – Wheeled base for easy repositioning
Stainless-ready option – High-efficiency filter cartridge for stainless steel welding fume extraction
